Automatic Thermoforming Vacuum Packaging Machine

The Automatic Thermoforming Vacuum Packaging Machine uses roll film instead of pre-made bags. The packaging process combines:

Film unwinding → Film forming → Product loading → Vacuuming → Heat sealing → Cutting → Finished product discharge

The film is heated and formed into the required package shape before the product is loaded. Vacuum extraction removes air from the package, followed by heat sealing and cutting.

This configuration is suitable for manufacturers that want to reduce manual bag preparation and keep forming and vacuum packaging in one machine.

Roll Film Thermoforming

The Automatic Thermoforming Vacuum Packaging Machine works with roll-fed packaging materials, eliminating the need to prepare individual bags in advance.

It supports films such as:

● Composite film

● Polyethylene (PE)

● Polyester (PET)

● Aluminum film

● Nylon and related multilayer films

Film thickness: 0.04–0.1 mm
Maximum film width: 200 mm

Vacuum & Heat Sealing

The vacuum system removes air from the formed package before heat sealing. Vacuum parameters and sealing conditions can be adjusted according to the product and packaging film.

A multi-stage vacuum system with industrial vacuum pump helps achieve stable air extraction. Optional gas flushing can be used for products requiring modified-atmosphere packaging.

Flexible Package Size

The MK-T50 supports a measuring range of:

Length: 40–160 mm
Width: 20–110 mm

This makes it suitable for small and medium-sized products with different package dimensions.

PLC Control

Vacuum time, sealing temperature, cooling time and operating speed can be adjusted through the PLC touchscreen.

Production parameters for different products can be stored and recalled when required.

Packaging Materials

Material	Thickness
Composite film	0.04–0.1 mm
PE film	0.04–0.1 mm
Polyester film	0.04–0.1 mm
Aluminum film	0.04–0.1 mm
Nylon film	0.04–0.1 mm

Actual film compatibility should be confirmed according to the forming and sealing characteristics of the selected material.



Technical Specifications

Parameter	MK-T50
Product Type	Automatic Thermoforming Vacuum Packaging Machine
Speed	12–60 bags/min
Packaging Length	40–160 mm
Packaging Width	20–110 mm
Film Thickness	0.04–0.1 mm
Max. Film Width	200 mm
Packaging Materials	Composite paper, PE, PET, aluminum film, nylon, etc.
Voltage	220V / 50Hz
Power	1.3 kW
Machine Weight	180 kg



Optional Functions

The machine can be equipped with additional functions according to the packaging process:

● Gas flushing

● Automatic feeding

● Inkjet coding

● Metal detection

● Checkweighing

● Product sorting

● Finished-product conveying

● Dust filtration

● Customized feeding system

For special products, the vacuum pump, sealing system and feeding configuration should be selected according to the product characteristics.



Applications

The Automatic Thermoforming Vacuum Packaging Machine can be used for vacuum packaging of:

Food

Cooked food, meat products, frozen products, nuts, grains, dried food and pickled products.

Agricultural Products

Mushrooms, dried aquatic products, tea and local specialties.

Medical & Healthcare

Selected medical supplies, dressings and moisture-sensitive products.

Hardware & Components

Small metal parts, accessories and electronic components requiring moisture or oxidation protection.

What to Consider Before Ordering

The suitable configuration depends mainly on the product and packaging film.

For liquid-rich products:

A liquid protection or separation structure may be required to prevent liquid from entering the vacuum system.

For hot products:

High-temperature-resistant sealing components and suitable films should be selected.

For powder products:

A dust filtration system can help protect the vacuum pump.

For flammable products:

Explosion-proof electrical and workshop safety measures should be assessed before production.

FAQ

What is the speed of the Automatic Thermoforming Vacuum Packaging Machine ?

The machine operates at 12–60 bags/min, depending on the product size, packaging material and operating conditions.

What film thickness can it handle?

The specified film thickness is 0.04–0.1 mm, with a maximum film width of 200 mm.

What is the packaging size range?

The specified range is 40–160 mm in length and 20–110 mm in width.

Can it use roll film?

Yes. The thermoforming configuration uses roll film to form the package before vacuuming and sealing.

Can the machine package different products?

Yes. The machine can be used for food, agricultural products, selected medical supplies and small hardware, provided the product and film are compatible with the machine.

Can KEDE customize the machine?

Yes. Feeding, vacuum, sealing and downstream functions can be configured according to the product, film and required production process.
